Cat6a Keystone Jack RJ45

S/FTP Cat.6A keystone jack Shielded and toolless, type 110

MPN: NAW-KSTO6ASL
  • Shielding: S/FTP
  • Configuration: 110 Type
  • Ports: 1

Cat6a Keystone Jack RJ45

S/FTP Cat.6A keystone jack Shielded and toolless, type 110

MPN: NAW-KSTO6ASL

Cat.6A keystone jack Shielded, toolless and 110 type

Our fully shielded (S/FTP) category 6A keystone jack is designed to transmit data at 10 gigabits per second while ensuring stable operation at 500MHz or higher frequencies and works with any board wall mount box or keystone type surface. This modular connector features nickel plated phosphor bronze contacts with 50 micro-inch gold plating. Easy to install, allows termination by hand or using a punch to block 110. This module allows connections to solid and stranded conductors with gages ranging from 23 to 26 AWG (American Wire Gage), and meets ANSI/- TIA/EIA-568 C.2 broadcast standards. It has ISO/IEC 11801, IEC 60603-7-5 and UL 94-V2 certifications. The connector includes an overall metal shield that provides a conductive path to ground, which meets the requirements of IEEE 802.3af and IEEE 802.3at for Power-over-Ethernet applications (PoE).

Color

Transmission speed

10000Mbps
